Toro 38816 - Checking and Adjusting the Auger;Impeller Cable; Checking the Auger Gearbox Oil Level

Figure37
3.Loosenortightentheturnbuckletoadjustthespring
lengthto5.5cm(2.18inches).
3
g019048
4
Figure38
1.Jamnut
3.Spring
2.Turnbuckle
4.2.18inches(5.5cm)
4.Tightenthejamnut(Figure38),ensuringthereisslight
tensiononthecable.
5.Ifthetractioncableisproperlyadjustedbutaproblem
remains,contactanAuthorizedServiceDealer.
CheckingandAdjustingthe
Auger/ImpellerCable
ServiceInterval:Aftertherst2hours—Inspectthe
auger/impellercableandadjustitif
necessary.
Yearly—Inspecttheauger/impellercableandadjust
orreplaceitifnecessary.
1.Loosenthejamnut.
2.Engagetheauger/impellerleverandholditinplace
(
Figure39).
Figure39
3.Loosenortightentheturnbuckletoadjustthespring
lengthto7cm(2.75inches)(Figure40).
2
1
3
g019047
4
Figure40
1.Jamnut
3.Spring
2.Turnbuckle
4.7cm(2.75inches)
4.Tightenthejamnut(Figure40),ensuringthereisslight
tensiononthecable.
5.Iftheauger/impellercableisproperlyadjustedbut
aproblemremains,contactanAuthorizedService
Dealer.
CheckingtheAugerGearbox
OilLevel
ServiceInterval:Yearly—Checktheaugergearboxoiland
addoilifnecessary.
1.Movethemachinetoalevelsurface.
2.Cleantheareaaroundthepipeplug(
Figure41).
22
