Toro 38816 - Product Overview; Operation; Freewheeling or Using the Self-Propel Drive

ProductOverview
g018887
Figure15
1.Hand-grip(2)
9.Dischargechute
2.Auger/impellerlever10.Scraper
3.Speedselectorlever
11.Auger
4.QuickStick™discharge
chutecontrol
12.Skid(2)
5.Tractionlever13.Electricstarterbutton
6.Fueltankcap14.Electricstarterplug
7.Engineoillltube/dipstick15.Snowcleanouttool
8.Chutedeector
g018888
Figure16
1.Choke
5.Recoilstarter
2.Ignitionswitch
6.Oildrainplug
3.Fuelshutoffvalve
7.Primer
4.Throttle
Figure17
1.Snowcleanouttool(attachedtothehandle)
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
FreewheelingorUsingthe
Self-propelDrive
Youcanoperatethesnowthrowerwiththeself-propelfeature
engagedordisengaged(freewheeling).
Tofreewheel,slidethewheelsinwardandinserttheaxle
pinsthroughtheaxleholes,butnotthroughthewheelhubs
(Figure18).
g019015
Figure18
Toself-propel,axlepinthroughtheholesinthewheelhubs
andtheinneraxleholes(Figure19).
g019014
Figure19
