Toro 38816 - Checking the Tire Pressure; Checking the Skids; Checking the Traction Drive Operation

6
CheckingtheTirePressure
NoPartsRequired
Procedure
Thetiresareoverinatedatthefactoryforshipping.Reduce
thepressureequallyinbothtirestobetween17and20psi
(116and137kPa).
7
CheckingtheSkids
NoPartsRequired
Procedure
RefertoCheckingandAdjustingtheSkidsinMaintenance.
8
CheckingtheTractionDrive
Operation
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
1.Starttheengine;refertoStartingtheEngine.
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector.
3.Squeezethelefthand(traction)levertothehand-grip
(
Figure14).
Figure14
Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure5).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure5).
D.Connectthetrunniontothespeedselectorlever
(Figure5).
4.Releasethetractionlever.
5.MovethespeedselectortothePosition1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(
Figure14).
Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure5).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure5).
D.Connectthetrunniontothespeedselectorlever
(Figure5).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable)or
takethemachinetoanAuthorizedServiceDealerfor
service.
12
