51
BEFORE SPRAYING
System Set-up:
IMPORTANT: INSPECT AND CLEAN ALL
SYSTEM COMPONENTS BEFORE SPRAYING,
INCLUDING THE TANK, STRAINER, PUMP,
SOLENOIDS, AND NOZZLES IN YOUR
INSPECTION.
1. Attach Supply Hose to Anti-siphon device and
fill the Tank half full with clean, clear water. Open
the Suction Line Valve.
2. Start engine. Refer to "Starting Engine" section
on page 22. Move the Throttle Lever to 7/8 to full
throttle to simulate desired spraying speed.
3. Turn the Spray Pump Control Switch to the
"ON" position.
4. Turn the Jet Agitator Switch to the "ON"
position.
5. Switch "ON" the Master Boom Switch and all
three individual Boom Switches.
6. Using the Pressure Adjust Switch, set the
Pressure Gauge to the desired operating pressure.
7. Confirm boom operation by switching Boom
Sections "ON" and "OFF".
8. Turn Master ON/OFF Switch to the "OFF"
position.
9. Refer to Filling The Solution Tank.
OPERATION
USING THE SPRAYER:
1. With Spray Pump switch "ON" and Master
Boom switch "OFF"; drive the vehicle to the area
to be sprayed.
2. With spray system at desired operating
pressure to achieve the application rate of the
chemical selected (see step 6 in "System Set-Up"
above), proceed as follows:
3. Position Throttle Control at 7/8 to full engine
speed to provide for necessary ground speed,
pressure, and volume.
4. Switch the Master ON/OFF Switch to "ON" and
use the Master ON/OFF, Remote Master, or
Individual Boom Switches to control the Boom
Sections.
WHILE OPERATING THE SPRAYER:
 Do not overlap areas that have been sprayed
previously.
 Watch for plugged Nozzles. Replace all worn
Nozzles or those producing streaks or uneven
patterns
 Stop the spray flow before stopping the
vehicle.
CAUTION
CHEMICALS ARE HAZARDOUS AND CAN
CAUSE PERSONAL INJURY!
Carefully read the directions printed on
the chemical manufacturer's labels
before handling chemicals. Instructions
on chemical manufacturer's container
labels, regarding mixing proportions,
should be read and strictly followed.
Keep spray material from skin. If spray
material comes in contact with body,
wash it off immediately with clean water
and detergent.
Always wear goggles and other
protective equipment as recommended
by the Chemical Manufacturer.
FILLING THE SOLUTION TANK:
IMPORTANT: Follow the chemical
manufacturer's instructions for mixing spray
solution to obtain desired application rate. Do
not add chemical to Tank until just before use.
The concentrate should not be poured into an
empty Tank: Fill tank about one-half full with
clean, clear water. With agitation ON, add
chemical concentrate and finish filling Tank with
water.
1. Refer to "Operation" section.
