60
PERFORMANCE VERIFICATION
Refer to the preceding information in this manual for complete and detailed instructions.
Follow all Safety Instructions .
Gallons Per Acre
Determine Desired Application Rate From
Manufacturers Labeling ________ G.P.A.
Determine a Vehicle Application Speed _____
M.P.H.
Verify Nozzle Spacing is 20.
Determine Gallons Per Minute
G.P.M. (See
Nozzle Chart on Page 7)and Use The Following
Formula to verify.
G.P.A. X M.P.H. X 20
5940
x x 20 = = G.P.M.
5940 5940
Select Nozzle Size (See Nozzle Chart on
Page 7)
based on G.P.M.
Determine Application Pressure
P.S.I.
(See Nozzle Chart on Page 7).
Set Up Spray System
Set Parking Brake.
Fill tank ½ full with water DO NOT add Chemical at this time.
Install Correct Nozzles.
Open Suction Valve Handle.
Turn Pump On.
Turn Booms On.
Set Pressure to P.S.I.
Visually Inspect The Output Of All Nozzles.
Turn Booms and Pump Off.
Perform Rate Check.
Gallons Per 1,000 sq. ft.
Determine Desired Application Rate From
Manufacturers Labeling ________ G.P. 1,000 sq. ft.
Determine a Vehicle Application Speed _____
M.P.H.
Verify Nozzle Spacing is 20
Determine Gallons Per Minute
G.P.M. ( See
Nozzle Chart on Page 7) and Use The Following
Formula to verify
G.P. 1,000 sq. ft. X M.P.H. X 20
136
x x 20 = = G.P.M.
136 136
Select Nozzle Size (See Nozzle Chart on Page 7)
based on G.P.M.
Determine Application Pressure
P.S.I.
(See Nozzle Chart on Page 7)
Rate Check
Verify G.P.A. application rate via 1/128th Acre Method
Mark off a test course in a flat area at 204 feet.
Drive the Sprayer with a ½ full tank of water at selected application speed and record the time it takes to
drive 204 feet.
seconds. NOTE: It is important to maintain your application speed during test.
