Rate Check (Contd)

Park Vehicle. SET PARKING BRAKE.

Turn on pump and all booms and maintain

P.S.I (predetermined).

Hold a graduated cylinder under the far left nozzle on the left boom. Collect the output for the same

amount of time that it took to travel 204 ft.

Each ounce of fluid collected equals a 1 gallon per acre application rate.

Repeat collection test twice for each nozzle record amount collected each test below.

Proceed through each column separately and completely.

Each Nozzle Should Be Within ± 5% Of The Average Of All Nozzles

Replace Each Nozzle Not ± 5% Of The GPA Average Range

Replace All Nozzles If Two or More Are Not Within The ± 5% GPA Range

Gallons Per 1,000 sq. ft.

Average 1 x .95 = ÷ 43.56 = = -5% G.P. 1,000 sq. ft.

Average 1 x 1.05 = ÷ 43.56 = = +5% G.P. 1,000 sq. ft.

(GPA Range) (GP 1,000 sq. ft. Range)

#1 oz/GPA

#2 oz/GPA

#3 oz/GPA

#4 oz/GPA

#5 oz/GPA

#6 oz/GPA

#7 oz/GPA

#8 oz/GPA

#9 oz/GPA

#10 oz/GPA

#11 oz/GPA

Total

÷11

Average 1 GPA

Both Averages Should Be Within 5% Of Each Other

CALCULATE RANGE

Gallons Per Acre

Average 1 x .95 = = -5%

Average 1

x 1.05 = = +5%

(GPA Range)
