MountingtheDebrisBlowerto
theTractionUnit
Partsneededforthisprocedure:
1Debrisblowerassembly
1Lockingpin
1Hairpincotter
Procedure
1.Removeanyattachmentfromthefrontofthemachine.
2.Movethetractionunitintopositionbehindthe
attachmentadapter.
3.Raisethetractionunitadapterintotheattachment
adapter.
Note:Ifthejackstandisraisedslightlyhigherthan
thecastors,theadapterwillbeeasiertoinstall.
4.Insertthelockingpinthroughtheadaptersandsecure
withahairpincotter(
Figure12).
1
2
G023910
Figure12
1.Lockingpin2.Hairpincotter
5.Installthedriveshafttothequickattachframeby
slidingthequickcouplerontotheshaft(Figure13).
1
2
G021678
Figure13
1.Driveshaft2.Quickattachframeshaft
6.Securethesafetychaintothequickattachframe
(Figure13).
7.Removethedustplugsfromthehydrauliccouplers
andmakesurecouplersarefreeofanydirtor
contamination.
8.Connecttheattachmenthydraulichosecouplerstothe
hydrauliccouplersonthetractionunitrearauxiliary
hydraulicpowerkit.
Important:Wheneverthehydraulichose
couplersaredisconnected,makesurethedust
plugsarecleanedandtheninstalledtoprevent
contaminationfromenteringeitherhydraulic
system.
