Page #17 background imageLoading...
Page #17 background image
111-1033TH051006
INTRODUCTION
The Toro Reelmaster® 3220-D is a diesel engine powered self propelled machine with hydraulic sys-
tems for ground drive, cutterhead drives and steering. The machine operates in two wheel drive.
The 3240-D machine also is a diesel engine powered self propelled machine and operates in two wheel
drive with automatic four wheel drive on demand. A differential lock function may be selected. The
transmission system is converted automatically to engage drive to all 4 wheels when the machine speed
decreases as a result of front wheel traction slip. 2WD is automatically re-engaged when traction slip is
reduced.
The Toro Reelmaster® 3220-D and 3240-D are precision built machines designed solely for cutting grass
and similar low lying ground vegetation within the limitations stated in this manual. Use in any other
way is considered as contrary to the intended use. Compliance with and strict adherence to the condi-
tions of operation, service and repair as specified in this Operators Manual also constitute essential ele-
ments of the intended use. The way in which these machines are operated and maintained will have a
profound effect on its performance and reliability.
This manual contains advice on the Toro Reelmaster® 3220-D and 3240-D which should be operated, ser-
viced and repaired only by persons who are familiar with their particular characteristics and who are
acquainted with the relevant safety procedures.
The safety precautions listed herein and all other generally recognised regulations on safety and all road
traffic regulations must be observed at all times.
Any arbitrary modifications carried out to these machines may relieve The Toro Company of liability for
any resulting damage or injury.
In the pursuit of continuous product development The Toro Company reserves the right to alter specifica-
tions without notice.
Cutterhead Variants: The Toro Reelmaster® 3220-D and 3240-D can be fitted with a range of cutter-
head configurations and optional extras:
Optional Extras:
Beacon Kit - Amber flashing warning light.
Lighting Kit - Complies with EC traffic regulations.
R.O.P.S. Cab - Full weather protection and roll - over protection.
Note: with a R.O.P.S. Cab fitted stability angle will decrease on both the RM3220-D and
RM3240-D, due to the higher centre of gravity of the machine.
When fitting optional extra kits to the mower be sure to fix the serial number decal supplied with the
kit to the rear bulkhead underneath the engine cover. This will help the Toro spare parts department to
supply the correct spare parts throughout the service life of the mower.
Left and Right: Throughout this manual the terms 'Left' and 'Right' refer to the machine when looking
in the direction of forward travel.
Fixed
Heads
Cutterhead
Number of bladesCylinder diameter
MK3 Cutterhead
200mm (8")
4, 6, 8, 10.
Floating Heads with smooth
or grooved front rollers
254mm (10")
4, 6
INTRODUCTION
1.17
1.17
