TROUBLE SHOOTING
PROBLEM
Lack of transmission
drive.
Forward/backward
transmission creep in
neutral.
Lack of steering.
POSSIBLE CAUSE
Parking brake engaged.
Low oil level.
Incorrect oil used.
Defective drive pedal linkage.
Defective transmission pump.
Transmission relief valve open.
Broken drive coupling.
Transmission filter
blocked.
Transmission neutral adjustment incor-
rectly set.
Defective steering valve.
Defective hydraulic cylinder.
Damaged steering hose.
TROUBLE SHOOTING Continued.
REMEDY
Release parking brake.
Fill reservoir to correct
level.
Drain reservoir and refill
with correct oil.
Check linkage and replace
defective parts.
Have the transmission
pump overhauled by your
Toro dealer.
Close relief valve, refer -
Operating the mower-
TOWING.
Replace drive coupling.
Replace transmission filter.
Readjust transmission neu-
tral linkage setting.
Service or replace steering
valve.
Service or replace hydraulic
cylinder.
Replace defective hose.
