Toro 74274 - Electrical System Maintenance; Servicing the Fuses

Important:Alwayskeepthebatteryfullycharged
(1.265specicgravity).Thisisespeciallyimportant
topreventbatterydamagewhenthetemperatureis
below32°F(0°C).
1.Makesurethellercapsareinstalledinbattery.
Chargebatteryfor10to15minutesat25to30amps
or30minutesat10amps.
2.Whenthebatteryisfullycharged,unplugthecharger
fromtheelectricaloutlet,thendisconnectthe
chargerleadsfromthebatteryposts(Figure44).
3.Installthebatteryinthemachineandconnectthe
batterycables,refertoInstallingtheBattery.
Note:Donotrunthemachinewiththebattery
disconnected,electricaldamagemayoccur.
G000960
1
2
3
4
Figure44
1.PositiveBatteryPost
3.Red(+)ChargerLead
2.NegativeBatteryPost
4.Black(-)ChargerLead
ServicingtheFuses
Theelectricalsystemisprotectedbyfuses.Itrequires
nomaintenance,however,ifafuseblowscheck
component/circuitformalfunctionorshort.
Fuse:
•Ignition,F1-30amp,blade-type
•Radiatorfan,F2-40amp,blade-type
1.Unlatchtheenginehoodandraisetheenginehood
togainaccesstofuseholder(Figure45).
2.Toreplacethefuses,pulloutonthefusetoremove
it.
3.Installanewfuse(Figure45).
G000967
1
2
3
Figure45
1.Leftsidefueltank3.Radiatorfan-40amp
2.Ignition-30amp
38
