StoppingtheEngine
CAUTION
Childrenorbystandersmaybeinjuredifthey
moveorattempttooperatethetractorwhileitis
unattended.
Alwaysremovetheignitionkeyandsettheparking
brakewhenleavingthemachineunattended,even
ifjustforafewminutes.
Figure18
Important:Makesurethatthefuel-shutoffvalveis
closedbeforetransportingorstoringthemachine,as
fuelleakagemayoccur.Beforestoringthemachine,pull
wireoffsparkplug(s)topreventpossibilityofaccidental
starting.
UsingtheSafety-Interlock
System
CAUTION
Ifthesafety-interlockswitchesaredisconnectedor
damaged,themachinecouldoperateunexpectedly,
causingpersonalinjury.
•Donottamperwiththeinterlockswitches.
•Checktheoperationoftheinterlockswitches
dailyandreplaceanydamagedswitchesbefore
operatingthemachine.
UnderstandingtheSafety-Interlock
System
Thesafety-interlocksystemisdesignedtopreventthemower
bladesfromrotatingunless1ofthefollowingoccur:
•Youmovetherightmotion-controllevertothecenter,
unlockedposition.
•Theblade-controlswitch(PTO)isengaged.
Thesafety-interlocksystemisdesignedtostopthemower
bladesifyoumoveorreleasetherightmotion-control
leverintotheNEUTRAL-LOCKposition.
Thehourmeterhassymbolstonotifyyouwhenthe
interlockcomponentisinthecorrectposition.Whenthe
componentisinthecorrectposition,atrianglelightsup
inthecorrespondingsquare.
Figure19
1.Triangleslightupwhentheinterlockcomponentsareinthe
correctposition.
TestingtheSafety-InterlockSystem
ServiceInterval:Beforeeachuseordaily
Testthesafety-interlocksystembeforeyouusethemachine
eachtime.
Note:Ifthesafetysystemdoesnotoperateasdescribed
below,haveanAuthorizedServiceDealerrepairthesafety
systemimmediately.
1.Starttheengine;refertoStartingtheEngine(page19).
2.Settheparkingbrake.
