PositioningtheFlowBafe
Thefollowingguresareonlyforrecommendeduse.
Adjustmentsvarybygrasstype,moisturecontent,andthe
heightofthegrass.
Note:Iftheenginepowerdrawsdown,andthemower
groundspeedisthesame,openupthebafe.
PositionA
Thisisthefull,rearposition(seeFigure30).Usethisposition
forthefollowing:
•Inshort,lightgrassmowingconditions
•Indryconditions
•Smallergrassclippings
•Propelsgrassclippingsfartherawayfromthemower
G012677
Figure30
PositionB
Usethispositionwhenbagging(Figure31).
G012678
Figure31
PositionC
Thisisthefull,openposition(Figure32).Useforthis
positionforthefollowing:
•Intall,densegrassmowingconditions
•Inwetconditions
•Lowerstheengine-powerconsumption
•Allowsincreasedgroundspeedinheavyconditions
G012679
Figure32
