Toro 74534TE GrandStand - Releasing the Cushion for Rear Access

Figure35
1.Removebattery
2.With2people,liftthefront
endofthemower(ensure
thattheplatformisup).
ReleasingtheCushionfor
RearAccess
Youcanreleasethecushionforrearaccesstothemachinefor
maintenanceoradjustment.
1.Lowertheplatform.
2.Removethehairpincottersoneachsideofthecushion.
3.Slidethelargewasherswithplasticbushingstothe
inside.
4.Removethecushionandlowerittotheplatform.
5.Performanymaintenanceoradjustmentonthe
machine.
6.Raisethecushionandslideitontothepinsonboth
sidesofthemachine(Figure36).
7.Slidethelargewasherswithplasticbushingsintothe
cushionbracketandsecurethemwithahairpin-cotter
pin(Figure36).
Figure36
