Toro 74765 - Page 43

G015129
1
2
3
4
5
4
6
Figure63
MowerDeckswith1Blade
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Spring-removaltool
Figure64
MowerDeckswith2Blades
1.Idlerpulley
4.Spring
2.Mowerbelt5.Enginepulley
3.Outsidepulley6.Spring-removaltool
6.Routethenewbeltaroundtheenginepulleyand
mowerpulleys(Figure63andFigure64).
7.Usingaspring-removaltool(ToroPartNumber
92-5771),installtheidlerspringoverthedeckhook
andplacetensionontheidlerpulleyandthemower
belt(Figure63andFigure64).
