OperatingtheParkingBrake
Alwayssettheparkingbrakewhenyoustopthemachineor
leaveitunattended.
SettingtheParkingBrake
1
2
G020305
Figure9
ReleasingtheParkingBrake
1
2
G020306
Figure10
OperatingtheThrottle
ThethrottlecontrolcanbemovedbetweenFastandSlow
positions(Figure11).
Alwaysusethefastpositionwhenturningonthemowerdeck
withthebladecontrolswitch(PTO).
G008946
Figure11
OperatingtheChoke
Usethechoketostartacoldengineasfollows:
1.Pulluponthechokeknobtoengagethechokebefore
usingtheignitionswitch(Figure12).
2.Pushdownonthechoketodisengagethechokeafter
theenginehasstarted(Figure12).
G008959
1
2
Figure12
1.On2.Off
OperatingtheIgnitionSwitch
1.TurntheignitionkeytotheStartposition(Figure13).
Whentheenginesstarts,releasethekey.
Important:Donotengagestarterformorethan5
secondsatatime.Iftheenginefailstostartallow
a15secondcool-downperiodbetweenattempts.
Failuretofollowtheseinstructionscanburnout
thestartermotor.
Note:Additionalstartingcyclesmayberequired
whenstartingtheengineforthersttimeafterthefuel
systemhasbeenwithoutfuelcompletely.
START
RUN
ST OP
G008947
Figure13
2.Tostoptheengine,turntheignitionkeytothestop
position.
