Toro 74855 - Positioning the Seat; Adjusting the Motion Control Levers

PositioningtheSeat
Theseatcanmoveforwardandbackward.Positiontheseat
whereyouhavethebestcontrolofthemachineandaremost
comfortable.
Whilesittingintheoperator'sposition,raisetheseat
adjustmentleverslightlyandmovetheseatforwardor
backwardtothedesiredposition(Figure24).
G010232
1
Figure24
1.Adjustmentlever
AdjustingtheMotionControl
Levers
AdjustingtheHeight
Themotioncontrolleverscanbeadjustedhigherorlowerfor
maximumoperatorcomfort.
1.Removethe2boltsand2washersholdingthecontrol
levertothecontrolarmshaft(Figure25).
2.Movethecontrollevertothenextsetofholes.Secure
theleverwiththe2boltsand2washers(Figure25).
4
1
2
G014970
3
Figure25
1.Controlarmshaft
4.Washer
2.Controllever
5.Bolt
3.Slotted,upperhole
3.Repeattheadjustmentfortheoppositecontrollever.
AdjustingtheTilt
Themotioncontrolleverscanbetiltedforwardorbackward
formaximumoperatorcomfort.
1.Loosentheupperboltholdingthecontrollevertothe
controlarmshaft.
2.Loosenthelowerboltjustenoughtoallowthecontrol
levertopivotforwardorbackward.
3.Alignthecontrolleverstothenewposition.
4.Tightenbothboltstosecurethecontrolleverposition.
5.Repeatsteps1,2,3and4toadjustmentfortheother
controllever.
23
