Toro 74855 - Engine Maintenance; Servicing the Air Cleaner

G009949
1
Figure28
1.Frontcastertire
4.Connectagreaseguntoeachtting(Figure28and
Figure27).Pumpgreaseintothettingsuntilgrease
beginstooozeoutofthebearings.
5.Wipeupanyexcessgrease.
EngineMaintenance
WARNING
Contactwithhotsurfacesmaycausepersonal
injury.
Keephands,feet,face,clothingandotherbody
partsawaythemuferandotherhotsurfaces.
ServicingtheAirCleaner
Note:Servicetheaircleanermorefrequently(everyfew
hours)ifoperatingconditionsareextremelydustyorsandy.
RemovingtheElement
1.Parkthemachineonalevelsurfaceanddisengagethe
bladecontrol(PTO).
2.Movethemotioncontrolleverstothebrakeposition,
stoptheengine,removethekey,andwaitforallmoving
partstostopbeforeleavingtheoperatingposition.
3.Cleanaroundtheaircleanercovertopreventdirtfrom
gettingintotheengineandcausingdamage.
4.Liftthecoverandremovethehoseclampsecuringthe
aircleanerassemblytotheengine(
Figure29).
5.Loosenthehoseclampandremovethepaperelement
(Figure29).
G015155
1
2
3
Figure29
1.Cover
3.Hoseclamp
2.Paperelement
28
