RemovingHydraulicSystemFilters
1.Stopengine,waitforallmovingpartstostop,and
allowenginetocool.
2.Removethekeyandengagetheparkingbrake.
3.Locatethelterandguardsoneachtransaxledrive
system(Figure47).
G010254
1
2
3
4
5
Figure47
Rightsideshown
1.Transaxledrive
4.Screws
2.Oillter
5.Ventplug
3.Filterguard
4.Removethreescrewssecuringthelterguardand
removetheguard(Figure47).
Note:Itisimportantthatnodirtorcontamination
enterhydraulicsystem.
5.Carefullycleanareaaroundlters.
6.Placeacontainerbelowtheltertocatchtheoilthat
drainswhenthelterandventplugsareremoved
(Figure48).
1
2
3
4
5
6
3/4
G0201 18
Figure48
7.Locateandremovetheventplugoneachtransmission
8.Rotatetheltercounterclockwisetoremovethelter;
allowoiltodrainfromdrivesystem.
Repeatthisprocedureforbothlters.
