13.Toadjustthesinglepointsystem,loosenthetwobolts
atthebottomoftheheightofcutplate.Referto
Figure88.
1
g017029
Figure88
1.Boltsatthebottomoftheheight-of-cutplate
14.Ifthedeckistoolow,tightenthesinglepoint
adjustmentboltbyrotatingitclockwise.Ifthedeckis
toohigh,loosenthesinglepointadjustmentboltby
rotatingitcounterclockwise(Figure89).
Note:Loosenortightenthesinglepointadjustment
boltenoughtomovetheheight-of-cutplatemounting
boltsatleast1/3thelengthoftheavailabletravel
intheirslots.Thiswillregainsomeupanddown
adjustmentoneachofthefourdecklinks.
g017036
Figure89
1.Singlepointadjustmentbolt
15.Tightenthetwoboltsatthebottomoftheheightofcut
plate(
Figure88).Torqueto27-33ft-lb(37-45N-m).
Note:Inmostconditions,thebackbladetipshould
beadjusted1/4inch(6.4mm)higherthanthefront.
16.Onbothsidesofthedeck,measurefromthelevel
surfacetothebacktipoftheblade(PostionB).
Themeasurementshouldread31/4inches(8.3cm)
(Figure86).
17.Fine-tunetheadjustmentnutonthefrontdecklift
assemblybyturningit(Figure87).
Toincreasetheheight,turntheadjustmentnut
clockwise;todecrease,turncounterclockwise.
18.Measureuntilallfoursidesarethecorrectheight.
Tightenallthejamnutsonthedeckliftarmassemblies.
19.Lowerdischargechute.
