5.Starttheengine.
Note:Engagetheparkingbrakeandmovethe
motion-controlleversoutbeforestartingtheengine.
Youdonotneedtobeintheseatbecauseofthe
jumperwirebeingused.Runtheengineatfullthrottle
andreleasethebrake.
6.Runthemachineatleast5minuteswiththe
motion-controlleversatfullforwardspeedtobringthe
hydraulicuiduptooperatingtemperature.
7.Bringthemotion-controlleversintotheNEUTRAL
position.
8.Adjustthepump-controlrodlengthsbyrotatingthe
doublenutsontherodintheappropriatedirection
untilthewheelsslightlycreepinreverse(Figure87).
g027342
Figure87
1.Doublenuts
9.Movethemotion-controlleverstotheREVERSE
position,andwhileapplyingslightpressuretothelever,
allowthereverseindicatorspringstobringthelevers
backtoneutral.
Note:Thewheelsmuststopturningorslightlycreep
inreverse.
10.Shutoffthemachine.
11.Removethejumperwirefromwireharnessandplug
theconnectorintotheseatswitch.
12.Removethejackstands.
13.Raisethedeckandinstalltheheight-of-cutpin.
14.Checkthatthemachinedoesnotcreepinneutralwhen
youdisengagetheparkingbrakes.
AdjustingtheMotion-Control
Damper
Youcanadjustthetopdampermountingbolttoobtaina
moredesiredmotion-controlleverresistance.SeeFigure88
formountingoptions.
Figure88
Rightmotion-controllevershown
1.Torquethelocknutto23N∙m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
57

Toro 74991 Z Master Professional 5000 Series Specifications

General

Engine	Kawasaki FX850V
Horsepower	27 hp
Transmission	Hydrostatic
Blade Tip Speed	18, 000 fpm
Deck Type	Fabricated
Cutting Width	60 in
Fuel Capacity	12.5 gal
Cutting Height	1.5 to 5 inches
Ground Speed	up to 10 mph
Tires	24 x 12-12
