AfterOperation
AfterOperationSafety
GeneralSafety
•Cleangrassanddebrisfromthecuttingunits,
mufers,andenginecompartmenttohelpprevent
res.Cleanupoilorfuelspills.
•Shutoffthefuelbeforestoringortransportingthe
machine.
•Disengagethedrivetotheattachmentwhenever
youaretransportingornotusingthemachine.
•Usefull-widthrampsforloadingthemachineinto
atrailerortruck.
•Tiethemachinedownsecurelyusingstraps,
chains,cable,orropes.Bothfrontandrearstraps
shouldbedirecteddownandoutwardfromthe
machine.
•Allowtheenginetocoolbeforestoringthemachine
inanyenclosure.
•Neverstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.
UsingtheFuel-Shutoff
Valve
Thefuel-shutoffvalveislocatedundertheseat.Move
theseatforwardtoaccessit.
Closethefuel-shutoffvalvefortransport,maintenance,
andstorage.
Ensurethatthefuel-shutoffvalveisopenwhen
startingtheengine.
g008948
Figure36
1.ONposition2.OFFposition
Usingthe
Drive-Wheel-Release
Valves
WARNING
Handsmaybecomeentangledintherotating
drivecomponentsbelowtheenginedeck,
whichcouldresultinseriousinjury.
Shutofftheengine,removethekey,andallow
allmovingpartstostopbeforeaccessingthe
drive-wheel-releasevalves.
WARNING
Theengineandhydraulicdriveunitscan
becomeveryhot.Touchingahotengineor
hydraulicdriveunitscancausesevereburns.
Allowtheengineandhydraulicdriveunits
tocoolcompletelybeforeaccessingthe
drive-wheel-releasevalves.
Thedrive-wheel-releasevalvesarelocatedinthe
backofeachhydraulic-driveunit,undertheseat.
Note:Makesurethatthereleasevalvesareinthe
fullyhorizontalpositionwhenoperatingthemachine;
otherwise,severedamagetothehydraulicsystem
canoccur.
1.Disengagetheblade-controlswitch(PTO),turn
theignitionkeytotheOFFposition,movethe
leverstotheNEUTRAL-LOCKposition,engagethe
parkingbrake,andremovethekey.
2.Rotatetherelease-valveleversverticallyto
pushthemachine.Thisallowshydraulicuidto
bypassthepump,enablingthewheelstoturn
(Figure37).
3.Disengagetheparkingbrakebeforepushing
themachine.
