Toro 75930 - Replacing the Grass Deflector; Cleaning; Cleaning under the Mower; Cleaning the Suspension System

ReplacingtheGrass
Deector
WARNING
Anuncovereddischargeopeningcouldallow
thelawnmowertothrowobjectsatyouor
bystanders,resultinginseriousinjury.Also,
contactwiththebladecouldoccur.
Neveroperatethelawnmowerunlessyou
installacoverplate,mulchplate,grass
deector,orbagger.
1.Removethelocknut,bolt,spring,andspacer
holdingthedeectortothepivotbrackets
(Figure104).
g015594
Figure104
1.Bolt
5.Springinstalled
2.Spacer6.Grassdeector
3.Locknut
7.J-hookendofspring
4.Spring
2.Removedamagedorworngrassdeector.
3.Placespacerandspringontothegrassdeector.
PlaceaJ-endofspringbehinddeckedge.
Note:EnsurethataJ-endofspringisinstalled
behinddeckedgebeforeinstallingtheboltas
showninFigure104.
4.Installtheboltandnut.
5.PlaceaJ-hookendofspringaroundgrass
deector(Figure104).
Important:Thegrassdeectormustbeable
torotate.Liftthedeectoruptothefullopen
positionandensurethatitrotatesintothe
fulldownposition.
Cleaning
CleaningundertheMower
ServiceInterval:Beforeeachuseordaily
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andsettheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Raisethemowertothetransportposition.
CleaningtheSuspension
System
Note:Donotcleantheshockassemblieswith
pressurizedwater(Figure105).
g030538
Figure105
DisposingofWaste
Engineoil,batteries,hydraulicuid,andengine
coolantarepollutantstotheenvironment.Disposeof
theseaccordingtoyourstateandlocalregulations.
69
