Toro 75930 - Greasing the Caster-Wheel Bearings; Lubricating the Caster-Wheel Hubs

g009030
Figure43
GreasingtheCaster-Wheel
Bearings
ServiceInterval:Yearly—Greasethefrontcaster
pivots(moreoftenindirtyordusty
conditions).
Yearly—Repackthefrontcaster-wheelbearings
(moreoftenindirtyordustyconditions).
1.Removethedustcapandadjustthecaster
pivots.
Note:Keepthedustcapoffuntilgreasingis
done.
2.Removethehexplug.
3.Threadagreasettingintothehole.
4.Pumpgreaseintothettinguntilitoozesout
aroundthetopbearing.
5.Removethegreasettinginthehole.
6.Installthehexpluganddustcap(Figure44).
g029643
Figure44
7.Greasethecaster-wheelbearings(Figure44).
Lubricatingthe
Caster-WheelHubs
ServiceInterval:Yearly
1.Shutofftheengine,waitforallmovingpartsto
stop,removethekey,andengagetheparking
brake.
g006115
Figure45
1.Sealguard2.Spacernutwithwrench
ats
2.Raisethemowerforaccess.
3.Removethecasterwheelfromthecasterforks.
4.Removethesealguardsfromthewheelhub.
5.Removeaspacernutfromtheaxleassemblyin
thecasterwheel.
Note:Thread-lockingadhesivehasbeen
appliedtolockthespacernutstotheaxle.
6.Removetheaxle(withtheotherspacernutstill
assembledtoit)fromthewheelassembly.
7.Pryoutsealsandinspectbearingsforwearor
damageandreplaceifnecessary.
8.Packthebearingswithgeneral-purposegrease.
9.Insert1bearingand1newsealintothewheel.
Note:Replacetheseals.
10.Iftheaxleassemblyismissingbothspacernuts,
applyathread-lockingadhesiveto1spacernut
andthreaditontotheaxlewiththewrenchats
facingoutward.
Note:Donotthreadthespacernutallof
thewayontotheendoftheaxle.Leave
approximately3mm(1/8inch)fromtheouter
surfaceofthespacernuttotheendoftheaxle
insidethenut.
11.Inserttheassemblednutandaxleintothewheel
onthesideofthewheelwiththenewsealand
bearing.
12.Withtheopenendofthewheelfacingup,ll
theareainsidethewheelaroundtheaxlefullof
general-purposegrease.
37
