Toro 75930 - Lubrication; Adding Light Oil or Spray Lubrication; Greasing the Mower Deck; Greasing the Pump-Belt-Idler Arm

Lubrication
Greasemorefrequentlywhenoperatingconditions
areextremelydustyorsandy.
GreaseType:No.2lithiumormolybdenumgrease
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Cleanthegreasettingswitharag.
Note:Makesurethatyouscrapeanypaintoff
thefrontofthetting(s).
4.Connectagreaseguntothetting.
5.Pumpgreaseintothettingsuntilgreasebegins
tooozeoutofthebearings.
6.Wipeupanyexcessgrease.
AddingLightOilorSpray
Lubrication
ServiceInterval:Every100hours
Lubricatethedeck-liftpivots.
g017050
Figure41
GreasingtheMowerDeck
ServiceInterval:Every50hours—Greasethemower
deckspindlesandidlerarm(if
applicable).
Important:Makesurethatthecuttingunit
spindlesarefullofgreaseweekly.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Greasethemower-deckidlerpulleypivotuntil
greasecomesoutthebottom(Figure42).
4.Ifyourmachinehasgreasablespindles,grease
the3spindlebearingsuntilgreasecomesout
thelowerseals(Figure42).
g009029
Figure42
Greasingthe
Pump-Belt-IdlerArm
ServiceInterval:Yearly—Greasethepump-belt-idler
arm.
Greasethepump-belt-idlerarm(Figure43).
