4.Removetheelectricalconnectionfromtheseat
safetyswitch,locatedunderthebottomcushion
oftheseat.
Note:Theswitchisapartoftheseatassembly.
5.Temporarilyinstallajumperwireacrossthe
terminalsintheconnectorofthemainwire
harness.
6.Starttheengineandrunitatfullthrottleand
disengagethebrake.
Note:Youdonotneedtobeintheseat,
becauseofthejumperwirebeingused.
7.Runtheunitforatleast5minuteswiththedrive
leversatfullforwardspeedtobringthehydraulic
uiduptotheoperatingtemperature.
Note:Themotion-controlleversneedsto
beinneutralwhilemakinganynecessary
adjustments.
8.Bringthemotion-controlleversintotheNEUTRAL
position.
9.Adjustthepumpcontrolrodlengthsbyrotating
thedoublenutsontherodintheappropriate
directionuntilthewheelsslightlycreepin
reverse(Figure85).
g029649
Figure85
1.Doublenuts
10.Movethemotion-controlleverstothereverse
positionandwhileapplyingslightpressureto
thelever,allowthereverse-indicatorspringsto
bringtheleversbacktoneutral.
Note:Thewheelsmuststopturningorslightly
creepinreverse.
11.Shutoffthemachine,removethejumperwire
fromthewireharness,andplugtheconnector
intotheseatswitch.
12.Removethejackstands.
13.Raisethedeckandinstalltheheight-of-cutpin.
14.Checkthatthemachinedoesnotcreepin
neutralwiththeparkbrakesdisengaged.
Adjustingthe
Motion-ControlDamper
Youcanadjustthetopdamper-mountingbolttoobtain
thedesiredmotion-controlleverresistance.Referto
Figure86formountingoptions.
g008620
Figure86
RightMotionControlShown
1.Torquethelocknutto23N-m(17ft-lb).Theboltmust
protrudepasttheendofthelocknutaftertorquing.
2.Mostresistance(rmestfeel)
3.Damper
4.Mediumresistance(mediumfeel)
5.Leastresistance(softestfeel)
