g008943
Figure67
1.ROPSknob(locked
position)
3.Rollbarintheupright
position
2.PulltheROPSknobout,
androtateit90degreesto
changetherollbarposition
4.Rollbarinthefolded
position
AdjustingtheTracking
1.Disengagetheblade-controlswitch(PTO).
2.Drivetoanopen,atarea,andmovethe
motion-controlleverstotheNEUTRAL-LOCK
position.
3.MovethethrottlemidwaybetweenFASTand
SLOW.
4.Movebothmotion-controlleversforwarduntil
theybothhitthestopsintheT-slot.
5.Checkwhichwaythemachinetracks.
6.Ifittrackstotheright,loosentheboltsandadjust
theleftstopplaterearwardontheleftT-slotuntil
themachinetracksstraight(Figure68).
7.Ifittrackstotheleft,loosentheboltsandadjust
therightstopplaterearwardontherightT-slot
untilthemachinetracksstraight(Figure68).
8.Tightenthestopplate(Figure68).
g035394
Figure68
Leftcontrollevershown
1.Controllever3.Stopplate
2.Bolt
CheckingtheTirePressure
ServiceInterval:Every50hours/Monthly(whichever
comesrst)
Maintaintheairpressureinthereartiresat90kPa
(13psi).Uneventirepressurecancauseunevencut.
Checkthetireswhentheyarecoldtogetthemost
accuratepressurereading.
Note:Thefronttiresaresemi-pneumatictiresanddo
notrequireairpressuremaintenance.
g001055
Figure69
52
