Toro 75969TE - Cleaning the Engine-Cooling Fins and Shrouds; Checking and Cleaning the Hydraulic Unit Shrouds

Cleaningthe
Engine-CoolingFinsand
Shrouds
ServiceInterval:Every100hours/Yearly(whichever
comesrst)
1.Disengagetheblade-controlswitch(PTO)and
engagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheair-intakescreen,therecoilstarter,
andthefanhousing(Figure79).
4.Cleanthedebrisandgrassfromtheengine
parts.
5.Installtheair-intakescreen,therecoilstarter,
andthefanhousing(Figure79).
g004218
Figure79
1.Engineguard4.Fanhousing
2.Engineair-intakescreen
5.Screw
3.Bolt
CheckingandCleaningthe
HydraulicUnitShrouds
ServiceInterval:Beforeeachuseordaily
Important:Thefastenersonthecoversofthis
machinearedesignedtoremainonthecover
afterremoval.Loosenallofthefastenerson
eachcoverafewturnssothatthecoverisloose
butstillattached,thengobackandloosenthem
untilthecovercomesfree.Thispreventsyou
fromaccidentallystrippingtheboltsfreeofthe
retainers.
1.Disengagetheblade-controlswitch(PTO)and
engagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Movetheseatforward.
4.Waitfortheengineandhydraulicsystemtocool.
5.Cleanthedebrisandgrassfromthehydraulic
unitshrouds(Figure80).
g206809
g010207
Figure80
1.Hydraulicunitshrouds
6.Overeachdipstick,removethecoverandthe
boltattachedtothecover.Cleanaroundeach
dipstickandhydraulicunit(Figure81).
56
