ReplacingtheHydraulic
Pump-DriveBelt
1.Disengagetheblade-controlswitch(PTO)and
engagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removethemowerbelt;refertoReplacingthe
MowerBelt(page58).
4.Raisethemachineandsupportitwithjack
stands(Figure86).
g009039
Figure86
1.Idlerpulley
5.Lefthydraulic-pumppulley
2.Clutchpulley6.Squareholeintheidler
arm
3.Pump-drivebelt7.Idlerspring
4.Righthydraulic-pump
pulley
5.Usearatchetinthesquareholeintheidlerarm
toremovetheidlerspring(Figure86).
6.Unhooktheidlerspringfromtheframe(Figure
86).
7.Removethebeltfromthehydraulic-unit-drive
pulleysandtheenginepulley.
8.Installthenewbeltaroundenginepulleyand
the2drivepulleys.
9.Usingaratchetinthesquareholeintheidler
arm,installtheidlerspringtotheframe(Figure
86).
10.Installthemowerbelt;refertoReplacingthe
MowerBelt(page58).
ControlsSystem
Maintenance
Adjustingthe
Control-HandlePosition
Thereare2heightpositionsforthecontrol
levers—highandlow.Removetheboltstoadjustthe
heightfortheoperator.
1.Disengagetheblade-controlswitch(PTO),move
themotion-controlleverstotheNEUTRAL-LOCK
position,andengagetheparkingbrake.
2.Shutofftheengine,removethekey,andwait
forallmovingpartstostopbeforeleavingthe
operatingposition.
3.Loosentheboltsandangenutsinstalledinthe
levers(Figure87).
4.Aligntheleversinthefront-to-rearpositionby
bringingtheleverstogethertotheNEUTRAL
position,andslidethemuntiltheyarealigned,
thentightenthebolts(Figure88).
g009040
Figure87
1.Bolt
3.Controllever
2.Handle4.Nut
