g009038
Figure84
1.Clutchpulley5.Squareholeintheidler
armfortheratchet
2.Mowerbelt
6.Idler-greasetting
3.Spring-loadedidlerpulley
7.Beltguide
4.Ratchet
12.Installthebeltguideontheidlerarm(Figure84).
13.Usingtheratchetinthesquarehole,installthe
idlerspring(Figure84).
Note:Makesurethatthespringendsare
seatedintheanchorgrooves.
14.Installthebeltcovers(Figure85).
g027730
Figure85
1.Positionthebeltcover3.Ensurethatthetabis
underthemetalcatch
2.Slidethebeltcoverunder
thesidecatches
15.Installthesheet-metalguard.RefertoRemoving
theSheet-MetalGuard(page40).
16.Tightentheboltforthemower-deckcurtain.
RefertoReleasingtheMower-DeckCurtain
(page39).
