Using the Lithium-Ion Battery Charger
G404840
G404841
Error indicator light
USB port cover
AC power indicator light
Battery charging indicator light
Charging output indicator light
LCD display
Select button
Output connector and cord
Power-supply cord
Connecting to a Power Source
To reduce the risk of electric shock, this charger has a 3-prong grounded plug (type B). If the
plug does not fit into the wall receptacle, other grounded plug types are available; contact an
authorized Toro distributor.
Do not change the charger or the power supply cord plug in any way.
DANGER
Contact with water while operating the machine could cause electric shock, causing
injury or death.
Do not handle the plug or the charger with wet hands or while standing in water.
Operation: Battery Operation Page 5–12 3460-892 A
