Toro Groundmaster 1018 - Maintenance; Checking the Reel-Driveshaft Grease Point

Maintenance
Checkingthe
Reel-DriveshaftGrease
Point
ServiceInterval:Yearly
1.Removethehardwarethatsecuresthereel-drive
assemblytothesideplate(Figure5).
g284793
Figure5
1.Socket-headscrew4.Springwasher
2.Spacer
5.Nut
3.Washer
2.Removethereel-driveassembly,atwashers,
springwashers,andspacersfromthesideplate
(Figure5).
3.Checktheinsideofthereeldriveshaft(Figure6)
foranyremaininggrease.
Ifyoudonotseeasufcientamountofgrease,
addmoregreasetothemaleandfemalespline
shaft.
g276424
Figure6
1.Reeldriveshaft
4.Usethepreviouslyremovedsocket-head
screws,washers,andspacerstosecurethe
reel-driveassemblytothesideplate.
5.Installthecuttingunittothetractionunit;referto
yourtractionunitOperator’sManual.
