Toro Groundmaster 1018 - 1 Installing the Roller; 2 Installing the Cutting Unit to the Traction Unit; Setup; 3 Adjusting the Cutting Unit

Setup
1
InstallingtheRoller
NoPartsRequired
Procedure
Thecuttingunitisshippedwithoutafrontroller.
ObtainarollerfromyourauthorizedT orodealerand
installitonthecuttingunit,asfollows:
1.Removetheplowbolt,washer,andangenut
securingoneoftheheight-of-cutarmstothe
cuttingunitsideplate(Figure3).
g275540
Figure3
1.Plowbolt5.Washer
2.Roller6.Flangenut
3.Height-of-cutarm
7.Roller-mountingscrew
4.Adjustingscrew
8.Cutting-unitassembly
2.Loosentheroller-mountingscrewsinthe
height-of-cutarms.
3.Slidetherollershaftintotheheight-of-cutarm
ontheoppositeendofthecuttingunit.
4.Slidetheheight-of-cutarmontotherollershaft.
5.Looselysecuretherollertothecuttingunitwith
theheight-of-cutarmandfastenerspreviously
removed.
6.Centertherollerbetweentheheight-of-cutarms.
7.Tightentheroller-mountingscrews.
8.Adjusttothedesiredheight-of-cutandtighten
theheight-of-cutarmmountingfasteners.
2
InstallingtheCuttingUnit
totheTractionUnit
NoPartsRequired
Procedure
Installthecuttingunittothetractionunit;referto
yourtractionunitOperator’sManualforinstallation
instructions.
3
AdjustingtheCuttingUnit
NoPartsRequired
Procedure
1.Accessthecuttingunitbyloweringthe
traction-unithandletotheground(Figure4).
g276933
Figure4
2.Adjustthebedknifetothereel;refertoAdjusting
theBedknifetotheReel(page8).
3.Adjusttheheightofcut;refertoAdjustingthe
HeightofCut(page11).
4.Adjustthegrassshield;refertoAdjustingthe
GrassShield(page13).
