Toro Groundsmaster 5900 Series Installation Instructions

4
InstallingtheHeadlights
(forMachineswithROPS
only)
Partsneededforthisprocedure:
1Rightheadlightmount
1
Leftheadlightmount
2
Coverpanel
8Plug
1Rightheadlightassembly
1
Leftheadlightassembly
Procedure
1.Unplugthewireharnessfromeachexistingheadlight.
2.Removetheheadlights(Figure6).
g188849
Figure6
1.Headlight2.Removethehardware
here.
3.Removeandretainthehardwarefromtheoperator’s
platform(Figure6).
4.Usingthefastenersthatyouremoved,installtheleft
andrightheadlightmountstotheexistingholesinthe
frontoftheoperator’splatform(Figure7).
g035974
Figure7
1.Headlightassembly3.Previouslyremoved
fasteners
2.Headlightmount
5.Removethefastenersfromtheheadlightassemblyand
usethemtomounttheheadlightstotheheadlight
brackets(Figure7).
6.Connectthewireharnesstotherightheadlight(Figure
8).
g036569
Figure8
1.Rightheadlightconnector
4.Connecttoexistingleft
headlightwireharness.
2.Connecttoexistingright
headlightwireharness.
5.Leftheadlightconnector
3.Frontturnsignalconnector
5

Toro Groundsmaster 5900 Series Specifications

General

Deck Lift	Hydraulic
Cutting Width	16 ft (4.9 m)
Drive System	4WD
Cutting Height	1 - 6 inches (2.5 - 15.2 cm)
Ground Speed	0-17 mph (0-27.4 km/h)
Transmission	Hydrostatic
Turning Radius	Zero-turn
Standard Tires	26 x 12-12
