Toro Groundsmaster 5900 Series Installation Instructions

7.Routethewireharnessthroughthebracketandunder
theoperatorplatform(Figure8).
8.Connectthewireharnesstobothconnectorsthatyou
unpluggedfromtheexistingheadlightsandconnect
thefrontturnsignalconnectortotheplatformwire
harness(Figure8).
9.Routethewireharnessthroughtheleftheadlight
bracketandconnectittotheleftheadlight(Figure8).
10.Installacoverpaneltoeachheadlightmountusing4
plugs.
5
InstallingtheHeadlights
(forMachineswithaCab
Only)
Partsneededforthisprocedure:
1Rightheadlightmount
1
Leftheadlightmount
1Rightheadlightassembly
1
Leftheadlightassembly
2
Bolt(1/2x1-1/4inches)
2
Nut(1/2inch)
2
Bolt(1/4x3/4inch)
2
Nut(1/4inch)
6
Cabletie
1Frontwireharness
Procedure
1.Installeachheadlightmounttothecabframeusing1
bolt(1/2x1-1/4inches),1nut(1/2inch),1bolt(1/4
x3/4inch),and1nut(1/4inch)asshowninFigure9.
g035976
Figure9
1.Headlight
4.Nut(1/2inch)
2.Bolt(1/2x1-1/4inches)5.Bolt(1/4x3/4inch)
3.Nut(1/4inch)
6.Headlightmount
2.Removethefastenersfromtheheadlightassemblies
andusethemtoinstalltheheadlightstothemounts.
3.Connectthewireharnesstotherightheadlight(Figure
10).
g036570
Figure10
1.Rightheadlightconnector
4.Connecttoexistingleft
headlightwireharness.
2.Connecttoexistingright
headlightwireharness.
5.Leftheadlightconnector
3.Frontturnsignalconnector
4.Routethewireharnessalongthebracketandunderthe
operatorplatform(Figure10).
6

Toro Groundsmaster 5900 Series Specifications

General

Deck Lift	Hydraulic
Cutting Width	16 ft (4.9 m)
Drive System	4WD
Cutting Height	1 - 6 inches (2.5 - 15.2 cm)
Ground Speed	0-17 mph (0-27.4 km/h)
Transmission	Hydrostatic
Turning Radius	Zero-turn
Standard Tires	26 x 12-12
