Toro HoverPro 550 User Manual

2
InstallingtheHandlebar
Partsneededforthisprocedure:
4T-bushings
2
Bolt(6x55mm)
6
Washer(6mm)
2
Locknut(6mm)
2Knob
2U-bolt
Handlebartting
1Upperhandlebar
1
Bolt(1/4x1-3/4inches)
1
Locknut(1/4inch)
AssemblingtheLowerHandlebar
totheMachine
1.Assemble2T-bushingsintothehandlebar
angesofthemowerdeck(Figure5).
g364682
Figure5
1.T-bushings
2.Handlebaranges(mower
deck)
2.Alignthefootstopofthehandlebartotheup-stop
bracketonthedeck(Figure6).
g364680
Figure6
1.Up-stopbracket2.Footstop
3.Aligntheholeinthehandlebarwiththeholesin
thebushings(Figure7),andsecurehandlebar,
tothemachinewithabolt(6x55mm),2
washers(6mm),andalocknut(6mm).
g364681
Figure7
1.Lowerhandlebar
3.Washer(6mm)
2.Bolt(6x55mm)4.Locknut(6mm)
4.Repeatstep3attheothersideofthemachine.
6
