Cylinder Head Exploded View and Service Information
Spark Plug
22 ft-lbs (36 Nm)
Cylinder Head Gasket
Valve Cover Gasket
Valve Cover
7.5 ft-lbs
(10 Nm)
Cylinder Head Bolt Torque Sequence:
1. Initially Torque the (4) Cylinder Head Bolts in a Crisscross Pattern to 10 ft-lbs (14 Nm).
2. Evenly Torque the (4) Cylinder Head Bolts in a Crisscross Pattern to 25 ft-lbs (34 Nm).
