28
Crankcase Exploded View
Oil Seal
Crankcase /
Sump Cover
Crankcase / Sump Cover Bolt
Torque Sequence
7.5 ft-lbs (10 Nm)
1
2
3
4
5
6
7
Sump Cover Gasket
Oil Dip Stick
O-Ring
Governor Arm Shaft
Governor Oil Seal
Governor Lock Pin
Oil Seal
