40
Electrical System Wiring (Electric Start Shown)
A Ignition Coil
B Starter Motor
C Alternator
D Brake / Kill Switch
E Starter Interlock Switch
F To Chassis Harness
G To Ground
E
D
B
A
C
G
F
F
