SECTION 5: KNOW YOUR LAWN TRACTOR
Figure 7
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A Systems Indicator Monitor/Hour Meter G Throttle / Choke Control
B PTO (Blade Engage) Lever H Ignition Switch Module
C Parking Brake Lever I Brake Pedal
D Cruise Control Lever J Drive Pedal
E Shift Lever K Deck Lift Lever
F Cup Holder
S
LO
W
A
G
K
J
I
NOTE: Steering Wheel not shown for clarity.
D
B
C
H
F
E
