Toro LX500 User Manual

6SDUN&LUFXLW
(ignition switch in “Normal”, PTO “on”)
LX420, LX460 2006
LX425, LX465 2007
 'HP\VWL¿FDWLRQ*XLGH
Circuits
Fuel Solenoid
(Energized)
IGNITION
MODULE
SPARK PLUG
Dashed lines do not carry current
GN
GN
Y
Y
Y
R
R
R
R
Y/BK
GN
GN
R R/W
R/W
R
BU
BU
GN
Y
Y/BK
Y/BK
Y/BK
Y/W
Headlight Harness
(Headlights on)
G
BA1
M
Ignition Switch
(In Normal)
Brake Switch
(Brake Off)
Seat Switch
(Operator On)
PTO Switch
(PTO On)
A1 Power
PB Bypass
Magneto
Ground
RMC Module
Rev Sw
Reverse Switch
(In Forward)
R/BK
Battery
Fuse
(20 Amp)
Park Sw
Park Switch
(Brake Off)
BN
BU
GY
W
PUR
R
PK
BK
Y
Y/BK
Y/W YELLOW WHITE
T
GN
OR
BROWN
BLUE
GRAY
WHITE
PURPLE
RED
PINK
BLACK
YELLOW
TAN
GREEN
ORANGE
WIRE COLOR CODES
R/W
YELLOW BLACK
RED WHITE
OR/BK
OR/W
ORANGE BLACK
ORANGE WHITE
R/BK RED BLACK
