Toro Power Plex 51481 - Unfolding and Adjusting the Handle

2
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Unfoldthehandle(AofFigure2).
2.Pressandholdthelockingbuttonontheuppershaft,alignthelockingbuttonwiththeslottedholeonthelowershaft,
andslidethe2shaftstogether.Oncetheslottedholeonthelowershaftispastthelockingbutton,releasethelocking
button,andslidethelowershaftintotheuppershaftuntilthetrimmerisatthedesiredheight(BofFigure2).
Note:Usethelockingbuttononlyforassemblyanddisassembly.Youdonotneedtousethebuttontoadjustthehandle.
3.Tightenthelowershaftconnectortosecurethehandleatthedesiredheight(CofFigure2).
g195351
Figure2
