InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1Auxiliaryhandle
Procedure
1.Lineupthegroovealongthehandlewiththegroove
ontheauxiliaryhandleandslidetheauxiliaryhandle
towardthetrimmerhandle(AofFigure3).
2.Snapthehandlesecurelyintoplace(BofFigure3).
g195362
Figure3
4
InstallingtheGuard
Partsneededforthisprocedure:
1
Guard
2Phillipsheadscrew
Procedure
1.Removethe2Phillipsscrewsthataretapedtothe
guardandslidetheguardontothetrimmerbase(A
ofFigure4).
2.Securetheguardontothebaseofthetrimmerwiththe
2Phillipsscrews(BofFigure4).
g203804
Figure4
5
InstallingtheEdgeGuard
Partsneededforthisprocedure:
1Wireedgeguard
Procedure
Slightlyspreadtheendsofthewireedgeguardapartand
inserttheendsintotheholesinthetrimmerhousingas
showninFigure5.
g203740
Figure5
