Toro PowerPlex 40 V MAX - Operation; Starting the Trimmer; Shutting Off the Trimmer; Removing the Battery Pack

Operation
StartingtheTrimmer
1.Makesurethattheventsonthetrimmerare
clearofanydustanddebris.
g194612
Figure6
1.Trimmerventingareas
2.Alignthecavityinthebatterypackwiththe
tongueonthehandlehousing(Figure7).
3.Pushthebatterypackintothehandleuntilthe
batterylocksintothelatch(Figure7).
g189881
Figure7
1.Batterylatch
4.Tostartthetrimmer,pressthelockoutbutton,
thensqueezethevariable-speedtrigger(Figure
8).
g189886
Figure8
1.Lockoutbutton2.Variable-speedtrigger
ShuttingOfftheTrimmer
Toshutoffthetrimmer,releasethetrigger.
Wheneveryouarenotusingthetrimmerorare
transportingthetrimmertoorfromtheworkarea,
removethebatterypack.
RemovingtheBatteryPack
fromtheTrimmer
Pressthebatterylatchonthemachinetoreleasethe
batterypackandslidethebatterypackoutofthe
machine(Figure9).
g192774
Figure9
1.Batterylatch
10
