ChargingtheBatteryPack
Important:Readallsafetyprecautions.
Important:Chargethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page9).
Note:Atanytime,pressthebattery-charge-indicator
buttononthebatterypacktodisplaythecurrent
charge(LEDindicators).
1.Makesurethattheventsonthebatterypackare
clearofanydustanddebris.
2.Lineupthecavityinthebatterypack(Figure10)
withthetongueonthecharger.
g228487
Figure10
1.Batterypackcavity4.Battery-charge-indicator
button
2.Batterypackterminals
5.LEDindicators(current
charge)
3.Batterypackventingareas
3.Makesurethattheventsonthebatterycharger
areclearofanydustanddebris.
4.Slidethebatterypackintothechargeruntilitis
fullyseated(Figure11).
g194423
Figure11
1.Chargerventingareas
3.Rightindicatorlight
2.Leftindicatorlight
5.Toremovethebatterypack,slidethebattery
backwardoutofthecharger.
6.RefertothefollowingtabletointerprettheLED
indicatorsonthebatterycharger.
LeftLight
RightLight
Indicates:
Off
Red
Chargerison;nobattery
packinserted
RedRedBatterypackischarging
Green
RedBatterypackischarged
Orange
RedBatterypackistoowarm
RedBlinkingRedReplacethebatterypack
AdvancingtheLine
Note:Thetrimmerisequippedwithanauto-feed
head.
1.Withthetrimmerrunning,releasetheswitch
trigger.
2.Waitafewseconds,thenpressthelockout
buttonandsqueezethetrigger.
Note:Thelineextendsapproximately6mm
(1/4inch)witheachstopandstartofthetrimmer
untilthelinereachesthelengthofthegrass
deectorblade.
3.Resumetrimming.
