3
Instalacióndela
empuñaduraauxiliar
Piezasnecesariasenestepaso:
1Empuñaduraauxiliar
Procedimiento
1.Alineelaranuradelmangoconlaranuradela
empuñaduraauxiliarydeslicelaempuñadura
auxiliarhaciaelmangodeladesbrozadora
(Figura3,A).
2.Encajermementelaempuñaduraensusitio
(Figura3,B).
g195362
Figura3
4
Instalacióndelprotector
Piezasnecesariasenestepaso:
1Protector
2TornilloPhillips
Procedimiento
1.Retirelos2tornillosPhillipsqueestánsujetos
concintaalprotectorycoloqueelprotectoren
labasedeladesbrozadora(Figura4,A).
2.Sujeteelprotectorenlabasedeladesbrozadora
conlos2tornillosPhillips(Figura4,B).
g203804
Figura4
9
