Operation
Note: Determine the left and right sides of the machine from the normal operating position.
Before Operation
Installing the Battery Pack
Important: Use the battery pack only in temperatures that are within the appropriate range; refer
to Specications ( page 1 1 ) .
1. Make sure that the vents on the battery are clear of any dust and debris.
2. Lift up the battery-compartment lid (A of Figure 7 ).
3. Line up the cavity in the battery pack with the tongue on the machine and slide the battery pack into the
compartment until it locks into place (B of Figure 7 ).
4. Close the battery-compartment lid (C of Figure 7 ).
Note: If the battery-compartment lid does not close completely , the battery is not fully installed.
g407696
Figure 7
Adjusting the Handle Height
Y ou may raise or lower the handle to a position comfortable for you.
T o adjust the handle height, do the following:
1. On both sides of the machine, rotate the handle locks (A of Figure 8 ).
2. Adjust the position of the handle to the upper (high handle height) or lower (lower handle height) position
(B of Figure 8 ).
3. When the handle is in the desired position, rotate the handle locks back until the pin clicks to secure the
handle (C of Figure 8 ).
12
