mechanical information and Note emphasizes general
information worthy of special attention.
Contents
Safety-Alert Symbol . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety and Instructional Decals . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 Assembling the Grass Bag . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Unfolding the Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Product Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
Specications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
Attachments/Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1
Before Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Installing the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Adjusting the Handle Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Adjusting the Cutting Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
During Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Starting the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Using the Self-Propel Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Recycling the Clippings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Bagging the Clippings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Shutting Of f the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Removing the Battery Pack from the
Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Operating T ips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
After Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Charging the Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Cleaning the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Folding the Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Storing the Machine in the V ertical-Stow
Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Lubricating the Machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Replacing the Blade . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adjusting the Self-Propel Drive . . . . . . . . . . . . . . . . . . . . . . . . . 20
Preparing the Battery Pack for
Recycling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
T roubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Safety
IMPORT ANT SAFETY
INSTRUCTIONS
W ARNING
When using electric lawn mowers, basic
safety precautions should always be followed
to reduce the risk of re, electric shock, and
personal injury , including the following:
Read All Instructions
I. T raining
1. The operator of the machine is responsible for
any accidents or hazards occurring to others or
their property .
2. Do not allow children to use or play with the
machine, battery pack, or the battery charger;
local regulations may restrict the age of the
operator .
3. Do not allow children or untrained people to
operate or service this machine. Allow only
people who are responsible, trained, familiar
with the instructions, and physically capable to
operate or service the machine.
4. Before using the machine, battery pack, and
battery charger , read all the instructions and
cautionary markings on these products.
5. Become familiar with the controls and proper
use of the machine, battery pack, and battery
charger .
II. Preparation
1. Keep bystanders, especially children and pets,
out of the operating area.
2. Do not operate the machine without all guards
and safety devices, such as deectors and grass
catchers, in place and functioning properly on
the machine.
3. Inspect the area where you will use the machine
and remove all objects that could interfere with
the operation of the machine or that the machine
could throw .
4. Before using the machine, ensure that the blade,
blade bolt, and blade assembly are not worn or
damaged. Replace any damaged or unreadable
labels.
5. Use only the battery pack specied by T oro.
Using other accessories and attachments may
increase the risk of injury and re.
6. Plugging the battery charger into an outlet that is
not 120V can cause a re or electric shock. Do
3
