Toro Reelmaster 3575-D - Page 92

Reelmaster 3550−D/3555−D/3575−DHydraulic System Page 4 − 60
Steering/Lift Circuit Testing − Lift Relief Valve (RV1) Pressure Test
(Reelmaster 3555−D and 3575−D)
Figure 37
PRESSURE
GAUGE
500 psi
2000 PSI
LIFT CYLINDER #1
BOR E: 1.50”
STROKE: 2.25”
ROD: 0.625”
EXTEND TO
LOW ER
C1
C4
GP
T
C5
RV2
S2
S4S3
S1
LIFT CONTROL MANIFOLD
C2
C3 C7
C6
C8
LIFT CYLINDER #4
BOR E: 1.50”
STROKE: 2.33”
ROD: 0.625”
EXTEND TO
LOW ER
LIFT CYLINDER #3
BOR E: 1.50”
STROKE: 2.25”
ROD: 0.625”
EXTEND TO
LOW ER
LIFT CYLINDER #2
BOR E: 1.50”
STROKE: 2.25”
ROD: 0.625”
EXTEND TO
LOW ER
LIFT CYLINDER #5
BORE: 1.50”
STROKE: 2.33”
ROD: 0.625”
EXTEND TO
LOW ER
.046”
.046”
.055”
.046”
.040” .040” .040” .035”
RV1
GEAR PUMP
(P2)
FROM
STEERING
CONTROL
TO
VALVE
