Toro Reelmaster 3575-D - Steering Control Valve and Steering Cylinder Test

Reelmaster 3550−D/3555−D/3575−DHydraulic System Page 4 − 64
Steering/Lift Circuit Testing − Steering Control Valve and Steering Cylinder Test
High Pressure
Low Pressure
Return or Suction
Flow
1000 PSI
P
L
ET
R
STEERING
PLUG
OPEN FITTING
STEERING
CONTROL
VALVE
CYLINDER
(REELMASTER 3550−D
VALVE SHOWN)
