Toro® - SnowMaster® Service Manual 3-11
Chassis
3
Table of Contents
CHASSIS
Transmission Cable Removal and
Replacement Figure 27)
Removal
1. Remove the LH upper shroud. Remove the belt
cover.
2. Remove the cable end from its retainer (Figure 28).
3. Remove the bolt from inside the belt cover (Figure
29).
4. Remove the two bolts holding the cable to the
chassis (Figure 30).
5. Remove cable from the spring.
Figure 28
Figure 29
Figure 30
